multifunction calibrators
What we offer?
Time Electronics multifunction calibrators are designed to calibrate both new and traditional test equipment. Each calibrator is built to maintain high accuracy and cover a wide calibration workload.
The calibrators are available with Traceable Calibration and UKAS Calibration, if ordered separately.
Time Electronics have a range of multifunction calibrators are designed to calibrate both new and traditional test equipment. Models encompass a wide range of capabilities to cover multiple functions. Each calibrator is built to maintain high accuracy and cover a wide calibration workload. The calibrators are available with Traceable Calibration and UKAS Calibration as option.
Application
This is a high performance precision multi-product calibrator designed to rapidly calibrate a wide range of test & measurement instruments namely, Multimeters, Clamp-on Meters, AC / DC voltage and current meters, Oscilloscopes, Power meters, Tachometers etc.
Specifications
- up to 15ppm accuracy
- Calibrate up to 6.5 digit meters
- 11 standard functions
- Source 2mV to 1050V AC with frequency 20Hz to 1 MHz Sine wave
- Source 0 – 1050V & 0 – ±22A (DC), 1100A through 50 turn coil
- Source Resistance, capacitance & conductance
- Source Thermocouple J, K, R, T, S, B, E, N, C, L, U / PT100, PT200, PT500, PT1000 simulation
- 2 wire variable Resistance 1Ω to 1.1 GΩ
- Source Digital Frequency / Period and AC Voltage Frequency
- Power 22A, 1050V, 23 kW, 40 to 500 Hz Calibration
- Phase / Power Factor factor ±90°C/ 0.00 to 1.00 PF Calibration
- Oscilloscope (available as options)
- RS232 output for PC installed with Time Electronics EasyCal Software
- Supplied with Basic Test Lead Set, Premium Test Lead Set S2PT2, PC Virtual Control Software, RS232 Cable, RS232 to USB Adaptor and User Manual
- Supplied with UKAS Calibration (if ordered separately)
Application
This is a high performance precision multi-product calibrator designed to rapidly calibrate a wide range of test & measurement instruments namely, Multimeters, Clamp-on Meters, AC / DC voltage and current meters, Oscilloscopes, Power meters, Tachometers etc.
Specifications
- up to 40ppm accuracy
- Calibrate up to 4.5 digit meters
- 11 standard functions
- Source 2mV to 1050V AC with frequency 20Hz to 1 MHz Sine wave
- Source 0 – 1050V & 0 – ±22A (AC/DC), 1100A through 50 turn coil
- Source Resistance, capacitance & conductance
- Source Thermocouple J, K, R, T, S, B, E, N, C, L, U / PT100, PT200, PT500, PT1000 simulation
- Variable Resistance 1Ω to 1.1 GΩ
- Source Digital Frequency / Period and AC Voltage Frequency
- Power 22A, 1050V, 23 kW, 40 to 500 Hz Calibration
- Phase / Power Factor factor ±90°C/ 0.00 to 1.00 PF Calibration
- Oscilloscope (available as options)
- RS232 output for Time Electronics EasyCal Software
- Supplied with Basic Test Lead Set, PC Virtual Control Software, RS232 Cable, RS232 to USB Adaptor and User Manual
- Supplied with UKAS Calibration (if ordered separately)
Oscilloscope Calibration
Option 5025C-S2/SCP:
- Amplitude: 2mV to 200V (1 Mohm) and 1mV to 2V 50Ω (Square-wave or DC)
- Frequency / Period: 0.1Hz to 10MHz / 100ns to 10s (fixed values 1,2, 5 sequence)
- Duty Cycle: 3 frequencies: 100Hz, 1 kHz, 10 kHz, selectable from 0 to 100%
- Fast-Rise: <400ps. Bandwidth checking up to 400 MHz
- Levelled Sine Wave 50 MHz to 2.2 GHz (0.5, 1, 1.5 V pk-pk)
Option 5025E-S2/SCP:
- Amplitude: 2mV to 200V (1 Mohm) and 1mV to 2V 50Ω (Square-wave or DC)
- Frequency / Period: 0.1Hz to 10MHz / 100ns to 10s (fixed values 1,2, 5 sequence)
- Duty Cycle: 3 frequencies: 100Hz, 1 kHz, 10 kHz, selectable from 0 to 100%
- Fast-Rise: <400ps. Bandwidth checking up to 400 MHz
- Levelled Sine Wave 50 MHz to 2.2 GHz (0.5, 1, 1.5 V pk-pk)
Option 9764: Current Probe Calibrator Adaptor (external option)
Option 9762: Rubidium High Stability Frequency Reference (external option)
Option 9780: Clamp Meter Adaptor (1 & 50 turn coil)
Option 9773: Optical Tacho Adaptor
Option 9790: 100 Amp AC Current Transformer
Option 9760: Power Amplifier (60 VAC, 90 VDC – 100 mA)
Option 9766: Low Noise Attenuator (1000:1)
Option 9767: Low Noise Attenuator (100:1)
Option S2PT2: Premium Test Lead Set (included as standard on 5025C)
Option 9085: Soft Carry Case
Option 9059: Hard Transit Case
Option 9728: 19″ Universal Rack Mount Kit
Option ACRD: UKAS Accredited (ISO 17025) Calibration Certificate for 5025C-S2/ACRD
Option ACRD: UKAS Accredited (ISO 17025) Calibration Certificate for for 5025E-S2/ACRD
Option ECFLA: EasyCal Calibration Software
Application
5051 Plus Calibration System combines a high accuracy calibration source with a precision digital multimeter. Designed for a wide workload the 5051 calibrates both traditional and new test equipment quickly and accurately.
By integrating the calibrator, DMM and PC in one unit minimal bench space is used in the laboratory to calibrate a wide range of test & measurement instruments namely, Multimeters, Clamp-on Meters, AC / DC voltage and current meters, Oscilloscopes, Power meters, Tachometers etc.
The 5051 control software allows the operator to easily select the wide range of functions using mouse, keyboard, or touch screen.
Specifications
- 10.4″ Touch Screen LCD
- up to 15ppm accuracy
- Calibrate up to 6.5 digit meters
- 11 standard functions
- Source 0 – 1050V & 0 – 22A (AC/DC)
- Measures 0 – 1000 VDC / 0 – 750 VAC & 0 – 3A DC / 0 – 3A AC
- Source capacitance & conductance
- Source & Measures Resistance
- Source & Measure Thermocouple / PT100
- Source Digital Frequency / Period and AC Voltage Frequency
- Oscilloscope Calibration (Amplitude, Frequency / Period, Duty Cycle & Fast Rise as standard)
- Oscilloscope (2.5 GHz sweep) & Power Calibration (available as options)
- 6.5 Digit Multimeter (measure)
- RS232 output for PC installed with Time Electronics EasyCal Software
- Supplied with Clamp Meter Adaptor, Premium Test Lead Set, Soft carry case, Printer and Connectivity Kit, Cal and ID Label Printer, EasyCal Calibration Software, NPL Traceable Factory Calibration Certificate and User Manual
- Supplied with UKAS Calibration (if ordered separately)
Oscilloscope Calibration Options
Option 9769: Internal Scope 2.2 GHz levelled Sine Generator
Option 9762: External Rubidium Frequency Reference
Option 9764: Current Probe Adaptor
Power Calibration
Option 9797:
- Power: 22A, 1050V, 23 kW, 45 to 400Hz
- Phase / Power Factor: ± 90° / 0.00 to 1.00PF
Option 9773: Optical Tacho Adaptor
Option 9790: 100 Amp AC Current Transformer
Option 9760: Power Amplifier (60 VAC, 90 VDC – 100 mA)
Option 9766: Low Noise Attenuator (1000:1)
Option 9767: Low Noise Attenuator (100:1)
